Universal Robots
6-AXIS COLLABORATIVE ROBOTS
Universal Robots are flexible, lightweight and user-friendly 6-axis industrial robots. They are developed specially for small and medium enterprises, which have the need for flexible and effective automation that can provide them fast return of investments. The robots are easy to move around and do not require sturdy bases due to their lightweight structure. Safety fencing is not needed. Equipped with intuitive programming, versatile use and an almost endless list of opportunities for add-ons, Universal Robots e-Series is able to complement production regardless of your industry, company size or product nature. Gibson Engineering is a proud Universal Robots distributor.
Universal Robots Product Solutions
UR3e Product Information
UR3e: Small but powerful, the UR3e has a payload of 3kgs and reach radius of 500mm. With 360 degree rotation on all wrist joints and infinite rotation on the end joint, this table- top cobot handles high precision tasks and light assembly tasks with ease.
Download the UR3e Brochure here
UR5e Product Information
UR5e: The medium-sized member of the Universal Robots family is ideal for automating low-weight processing tasks with its 5kgs payload and 850mm reach radius. Easy to program and fast to set up, the UR5e strikes the perfect balance between size and power. Download our brochure below for more on the UR5e specs and reach.
Download the UR5e Brochure here
UR10e Product Information
UR10e: With the ability to automate tasks up to 12kgs with no compromise on precision, the UR10e is the Universal Robots’ family’s most powerful robot. A reach radius of 1300mm also enables it to carry out tasks like packaging and palletizing in facilities where there is a larger distance between different operating areas.
Download the UR10e Brochure here
UR16e Product Information
UR16e: UR16e delivers an impressive 16kg (35.3 lbs.) of payload an 900mm reach within a small footprint, and is ideal for use in heavy machine tending, material handling, packaging, and screw and nut driving applications. This powerhouse robot allows for heavier end of arm tooling and multi-part handling, and is especially useful for achieving shorter cycle times.
Download the UR16e Brochure here
UR20e Product Information
UR20e: The UR20 is built for higher payloads, faster speeds, and superior motion control all within a lightweight, small footprint system for optimal versatility within your existing production space. No special electrical hookups or costly wiring solutions are required. Even with the big step up in performance, a single-phase standard power outlet is all that’s needed to power the UR20.
With a 1750 mm reach and 25 kg payload capacity, UR's next generation cobot handles more tasks, fits more applications, and assists in more environments than ever before.
Download the UR20 Brochure here
UR30 Product Information
The UR30 can lift heavy payloads while maintaining a compact footprint in a collaborative setting. With a 35 kg lifting capacity and a 1300 mm reach this robot can tend larger machines, palletize heavy products, and effectively support high torque screw driving.
With the ability to handle higher torque, the UR30 opens the door for precise screw driving and the 30 kg payload brings productivity to everything from machine tending with multiple grippers to palletizing heavy parts.
Download the UR30 Brochure here
AI Accelerator
The AI Accelerator is the perfect way to add artificial intelligence to your robotics solutions. The AI Accelerator offers endless possibilities to improve modern production. From improved decision making through computer vision to enhanced motion capabilities derived from training models.
What's in the box:
- Embedded NVIDIA Jetson Orin AGX 64GB compute box
- Orbbec Gemini 335Lg - 3D Vision camera
- Camera bracket & flange extender
- Cabling & cable guidance
- Flyer & manual
- USB cable (GMSL soon)
Universal Robots Downloads
View our Universal Robots downloads for technical specifications on UR robotics including the UR3e, UR5e, UR10e, and more!
Universal Robots Videos
e-Series Collaborative Robots
Easy Automation with Collaborative Robots
Unboxing Your Robot
Case Study: Automate Quality Control
Case Study: Machine Tending and Welding
Case Study: Enabling Flexible Automation
UR Robots are Compatible with
Robotic Grippers
End of Arm Tooling
Vision Guidance
Additional Safety
Material Presentation
Robot Mounting
Material Presentation
Contact to Get Started With Universal Robots
Built with the future in mind, the UR collaborative robots are designed to grow in capability alongside your business, a springboard to improved product quality and productivity, so you will always be able to stay ahead of competition. Equipped with intuitive programming, versatile use and an almost endless list of opportunities for add-ons, the UR arms are able to complement production regardless of your industry, company size, or product nature.
Reach out to Gibson Engineering to learn more or to get started automating today!
